群创 INNOLUX 工控 工业系列液晶屏

ModelName PanelSize Technology Resolution Luminance ViewAngle (U/D/R/L) Contrast Ratio Electrical Interface Pin LEDL/T Min. Operating Temperature LED MPQ
(nits) Driver
G057VGE-T01 EOL Q1'23 TN 640 x 480 450 70/70/80/80 800:01:00 TTL 33 50000 -30℃～85℃ 60
G057VCE-TH1 5.7" AAS 640 x 480 450 88/88/88/88 800:01:00 TTL 33 50000 -30℃～85℃ 60
G070Y2-L01 7" TN 800 x 480 500 60/60/70/70 600:01:00 LVDS 20 50000 -30℃～85℃ 34
G070ACE-LH3 7" AAS 800 x 480 500 89/89/89/89 800:01:00 LVDS 30 50000 -30℃～85℃ Yes 34
G070ACE-LH1 7" AAS 800 x 480 1000 89/89/89/89 800:01:00 LVDS 30 50000 -30℃～85℃ Yes 38
G070Y2-T02 EOL Q1'23 TN 800 x 480 500 60/60/70/70 600:01:00 TTL 60 50000 -30℃～85℃ 34
G070Y3-T01 7" TN 800 x 480 600 60/60/70/70 650:01:00 TTL 50 30000 -30℃～85℃ 40
G070ACE-L01 7" AAS 800x480 500 89/89/89/89 800:01:00 LVDS 30 50000 -30℃～85℃ Yes 38
G080Y1-T01 EOL Q1'23 TN 800 x 480 600 60/60/70/70 600:01:00 TTL 60 30000 -30℃～85℃ 40
G090WCE-P01 9" AAS 1280x720 O/C 88/88/88/88 1000:01:00 LVDS 40 4% -30℃～85℃ Yes 56
G101ICE-LM1 10.1 AAS 1280 X 800 350 88/88/88/88 800:01:00 LVDS 30 12000 -10℃～60℃ Yes 28
G101ICE-L01 10.1" AAS 1280 X 800 500 85/85/85/85 800:01:00 LVDS 40 50000 -20℃～65℃ 28
G101ICE-LH1 10.1 AAS 1280 X 800 500 88/88/88/88 800:01:00 LVDS 30 50000 -30℃～80℃ Yes
G101ICE-LH2 NEW AAS 1280x800 1000 LVDS 50000 -30℃～80℃
G101ICE-L03 EOL Q4'22 AAS 1280 X 800 500 85/85/85/85 800:01:00 LVDS 40 50000 -20℃～65℃ Yes 28
G104S1-L01 10.4" TN 800X600 400 70/70/80/80 700:01:00 LVDS 20 30000 -20℃～70℃ 16
G104AGE-L02 10.4" TN 800x600 400 80/80/70/70 700:01:00 LVDS 20 30000 -30℃～80℃ 16
G104ACE-LH1 NEW AAS 800x600 400 1000:01:00 LVDS 50000 -30℃～80℃
G104XCE-LM1 10.4" AAS 1024x768 350 88/88/88/88 1000:01:00 LVDS 30 50000 -20℃～70℃ Yes 24
G104XCE-L01 10.4" AAS 1024x768 500 88/88/88/88 1000:01:00 LVDS 30 50000 -30℃～80℃ Yes 24
G104XCE-LH1 10.4" AAS 1024x768 1000 88/88/88/88 1000:01:00 LVDS 30 50000 -30℃～85℃ Yes 24
G104ACJ-L01 10.4" AAS 960x1280 900 85/85/85/85 1000:01:00 LVDS 50 50000 -40℃～80℃ No 18
G121S1-L02 EOL Q1'23 VA 800x600 600 89/89/89/89 1500:01:00 LVDS 20 50000 -30℃～80℃ Yes 16
G121ACE-LH1 12.1" AAS 800x600 450 88/88/88/88 1000:01:00 LVDS 30 50000 -30℃～85℃ Yes 18
G121ACE-LH2 12.1" AAS 800x600 600 88/88/88/88 1000:01:00 LVDS 30 50000 -30℃～85℃ Yes 18
G121ACE-PH1 12.1 AAS 800x600 O/C 1000:01:00 -30℃～85℃
G121AGE-L03 EOL Q4'22 VA 800 x 600 450 89/89/89/89 1500:01:00 LVDS 20 50000 -30℃～80℃ 22
G121XCE-L01 12.1" AAS 1024x768 600 89/89/89/89 1000:01:00 LVDS 20 50000 -30℃～85℃ Yes 18
G121XCE-L02 12.1" AAS 1024x768 500 89/89/89/89 1000:01:00 LVDS 20 30000 -30℃～70℃ Yes 18
G121XCE-P01 12.1" AAS 1024x768 O/C 89/89/89/89 1000:01:00 LVDS 20 O/C -30℃～85℃ No 23
G121XCE-LM1 12.1" AAS 1024x768 1000 89/89/89/89 1000:01:00 LVDS 20 50000 -30℃～75℃ Yes 18
G121ICE-L01 12.1" AAS 1280x800 600 88/88/88/88 1000:01:00 LVDS 30 50000 -30℃～80℃ 18
G121ICE-L02 12.1" AAS 1280x800 400 80/80/80/80 1000:01:00 LVDS 30 30000 -20℃～70℃ Yes 18
G121ICE-LH1 12.1 AAS 1280x800 1000 85/85/85/85 1000:01:00 LVDS 30 50000 -30℃～80℃ Yes 20
G121ICE-LH2 12.1 AAS 1280x800 600 1000:01:00 LVDS 50000 -30℃～80℃
G121ICE-LM2 12.1 AAS 1280x800 400 1000:01:00 LVDS 30000 -30℃～80℃
G121ICE-P01 12.1" AAS 1280x800 O/C 88/88/88/88 1000:01:00 LVDS 30 O/C -30℃～80℃ Yes 56
N135NCG-GT1 13.5 AAS 1920x1280 400 89/89/89/89 1500:01:00 eDP 30 15000 0℃～50℃ Yes 20
G150XNE-L01 15" VA 1024x768 500 88/88/88/88 2500:01:00 LVDS 20 70000 -30℃～80℃ Yes 16
G150XNE-L02 15" VA 1024x768 350 88/88/88/88 2500:01:00 LVDS 20 50000 -30℃～70℃ Yes 16
G150XNE-L03 15" VA 1024x768 300 88/88/88/88 2000:01:00 LVDS 20 70000 -20℃～70℃ Yes 16
G150XJE-E01 15" VA 1024x768 400 88/88/88/88 2500:01:00 eDP 30 70000 -20℃～70℃ Yes 16
G150XJE-E02 15" VA 1024x768 400 88/88/88/88 2500:01:00 eDP 30 50000 0℃～60℃ Yes 16
G150XJE-E03 15" VA 1024x768 450 88/88/88/88 2500:01:00 eDP 30 50000 -20℃～70℃ Yes 16
G150XJE-E05 15" VA 1024x768 350 88/88/88/88 2500:01:00 eDP 30 50000 -20℃～70℃ Yes 16
G150XJE-P01 15" VA 1024x768 O/C 88/88/88/88 2500:01:00 LVDS 20 O/C -30℃～80℃ 4.60% 27
G154I1-LE1 15.4" TN 1280 x 800 450 70/70/80/80 700:01:00 LVDS 30 50000 -30℃～80℃ Yes 13
G154ICE-LH1 15.4 AAS 1280x800 450 89/89/89/89 700:01:00 LVDS 30 50000 -30℃～80℃ Yes 13
G156BGE-L01 EOL Q4'23 TN 1366 x 768 300 80/80/80/80 500:01:00 LVDS 30 50000 0℃～60℃ Yes 10
G156BGE-L03 EOL Q4'23 TN 1366 x 768 500 80/70/80/80 600:01:00 LVDS 30 50000 0℃～60℃ Yes 13
G156HCE-E01
15.6" AAS 1920 x 1080 450 89/89/89/89 1000:01:00 eDP 1.2 40 50000 0℃～50℃ Yes 18
G156HCE-L01
15.6" AAS 1920 x 1080 450 85/85/85/85 800:01:00 2ch-LVDS 40 50000 -30℃～85℃ Yes 18
G156HCE-LN1
15.6 AAS 1920 x 1080 350 89/89/89/89 1000:01:00 LVDS 40 50000 -20℃～70℃ Yes 18

G156HCE-P01
15.6" AAS 1920 x 1080 O/C 85/85/85/85 800:01:00 2ch-LVDS 40 O/C -30℃～85℃ 4% 27
G170ECE-LE1
17" AAS 1280x1024 250 1000:01:00 5000 0℃～60℃
G185BGE-L01
18.5" TN 1366x768 300 80/80/85/85 1000:01:00 LVDS 30 50000 0℃～60℃ Yes 8
G200HJJ-L01
19.53" VA 1920x1080 450 85/85/85/85 3000:01:00 LVDS 30 50000 0℃～50℃ No 15
G200HJJ-EN1
19.53" VA 1920x1080 350 85/85/85/85 3000:01:00 eDP 30 50000 0℃～50℃ Yes 15
G215HCJ-L01
21.5" AAS 1920x1080 400 89/89/89/89 1000:01:00 LVDS 30 50000 0℃～60℃ Yes 10
G215HCJ-L02
21.5" AAS 1920x1080 350 89/89/89/89 1000:01:00 LVDS 30 50000 0℃～60℃ No 10

G215HCJ-LH1
NEW AAS 1920x1080 1400 89/89/89/89 1000:01:00 LVDS 30 50000 -30℃～80℃ Yes
G238HCJ-L01
23.8" AAS 1920x1080 350 89/89/89/89 1000:01:00 LVDS 30 30000 0℃～50℃ No 12

G238HCJ-L02
23.8" AAS 1920x1080 450 89/89/89/89 1000:01:00 LVDS 30 50000 0℃～60℃ Yes 12
G238HCJ-LH1
NEW AAS 1920x1080 1000 88/88/88/88 1000:01:00 LVDS 30 50000 -30℃～80℃ Yes 10
N101ICG-L11
EOL Q3'22 AAS 1280 X 800 350 85/85/85/85 800:01:00 LVDS 40 12000 -10℃～60℃ Yes 30
N116HSE-EBC
EOL AAS 1920x1080 300 89/89/89/89 800:01:00 eDP 30 15000 -0℃～50℃ Yes 30

N125HCE-HN1
EOL Q4'22 AAS 1920x1080 O/C 89/89/89/89 700:01:00 eDP 30 O/C -0℃～50℃ ##### 40
N133HCE-GA1
EOL Q4'22 AAS 1920x1080 350 85/85/85/85 800:01:00 eDP 30 15000 -0℃～50℃ Yes 40

N140HCA-EAC
EOL Q3'22 AAS 1920x1080 220 89/89/89/89 700:01:00 eDP 30 15000 -0℃～50℃ Yes 20
N140HCG-GQ2
14" AAS 1920x1080 400 89/89/89/89 800:01:00 eDP 30 15000 -0℃～50℃ Yes 20
N156BGA-EB2
EOL Q1'23 TN 1366 x 768 220 20/45/45/45 600:01:00 eDP 30 15000 -0℃～50℃ Yes 20
N156HCE-EN1
15.6" AAS 1920 x 1080 300 89/89/89/89 700:01:00 eDP 30 15000 -0℃～50℃ Yes 20
M170EGE-L20
17" TN 1280 x 1024 250 80/80/85/85 1000:01:00 LVDS 30 50000 0℃～50℃ No 11
M215HJJ-L30
EOL Q4'22 VA 1920 x 1080 250 89/89/89/89 3000:01:00 2 ch LVDS 30 40000 -0℃～50℃ No 10
M315DJJ-K31
31.5" VA 3840x2160 400 89/89/89/89 3000:01:00 V by one 51 30000 -0℃～50℃ Yes 8
